@60% Duty
@100% Duty
Metal Body
The Genesis 400 Star uses advanced IGBT Module-based 20 kHz Full Bridge Inverter technology for stable arc control and high energy efficiency. The elevated OCV (Open Circuit Voltage) of 95–110V DC is specifically engineered to support demanding cellulosic electrode starting — essential for pipe welding in oil, gas, and construction applications.
The 330–500V wide input voltage range makes it particularly well-suited for construction sites in India where DG set or generator power is the primary supply — a common challenge for heavy infrastructure and pipeline projects.
| Input Specifications | |
|---|---|
| Input Voltage | 415 VAC, 3-Phase, 50/60 Hz |
| Voltage Range | 330 VAC – 500 VAC |
| Generator Compatibility | Yes |
| Input @ 400A | 17.8 KVA / 25A @ 415V |
| Input @ 310A | 12.5 KVA / 17.3A @ 415V |
| Input @ 250A | 9.3 KVA / 13A @ 415V |
| Input Cable | 4-core 2.5 sqmm, 4 meters |
| Switching Device | IGBT Module |
| Inverter Frequency | 20 kHz Full Bridge |
| Output Specifications | |
| Output Current Range | 10A – 400A |
| Output @ 60% Duty | 400A / 36V |
| Output @ 100% Duty | 310A / 32V |
| Open Circuit Voltage | 95 – 110 VDC |
| Welding Process | SMAW – DC Constant Current |
| Polarity | DC+ / DC− |
| Protection & Insulation | |
| Ingress Protection | IP23 |
| Insulation Class | Class H (180°C) |
| Cooling Method | Forced Air (Fan Cooled) |
| Thermal Protection | Auto Thermal Cutout |
| Mechanical Specifications | |
| Dimensions (L×W×H) | 650 × 345 × 600 mm |
| Weight | 53 kg |
| Body | Full Metal |
| Base | Rubber Foot |
| Lifting | Integrated Handle |
| * Specifications subject to change without notice. Contact APS Welding for latest data sheet. | |
| Welding Current | Arc Voltage | Input KVA | Input HP | Input Amps @ 415V |
|---|---|---|---|---|
| 400A | 36V | 17.8 KVA | 22.7 HP | 25A |
| 310A | 32V | 12.5 KVA | 15.8 HP | 17.3A |
| 250A | 30V | 9.3 KVA | 11.8 HP | 13A |
High Frequency unit enables smooth, contact-free TIG welding starts — no electrode contamination.
Elevated open circuit voltage ensures reliable, fast arc starting with cellulosic and low-hydrogen electrodes in all positions.
Dust and water splash rated — performs reliably in open yards, outdoor pipeline sites, and construction environments.
High output capacity with continuous duty cycle — handles 5.0mm electrodes and up to 25mm job thickness.
The Genesis 400 Star is a high-performance 400 Amp arc welding machine designed for demanding industrial applications. If you are searching for the latest 400 Amp arc welding machine price in India, APS Welding offers competitive pricing with reliable heavy-duty performance.
The Genesis 400 Star by APS Welding is a high-performance and rugged Stick Electrode ARC Welding Machine, engineered to meet the demands of the most challenging industrial applications. With a weight of just 53 kg, it is lightweight enough for easy portability, yet built tough enough to handle heavy-duty welding tasks. This machine is ideal for pipe welding and designed to meet the specific needs of industries like oil and gas, construction, infrastructure, and fabrication. It’s especially suited for cellulosic electrodes like E6010, E7010, E8010, and E9045, ensuring flawless performance in demanding environments.
Equipped with IGBT inverter technology, the Genesis 400 Star guarantees stable arc performance, high energy efficiency, and exceptional control over the welding process. The machine’s wide input voltage range of 330VAC to 500VAC allows it to operate reliably even under variable power supply conditions, making it perfect for use in construction sites or remote locations where power stability may vary. The machine is capable of delivering up to 400 amps at a 60% duty cycle, ensuring continuous power for long, intensive welding sessions without sacrificing performance.
The Genesis 400 Star features a rugged, metal body designed to withstand the toughest worksite conditions. It is built to last, with a high-quality construction that ensures long-term durability. At the same time, its lightweight design allows for convenient transportation between work sites, making it a versatile choice for mobile welders. Whether you’re working with mild steel, stainless steel, or carbon steel, this machine ensures precise and consistent welds with minimal spatter.
With its versatile capabilities, the Genesis 400 Star is the perfect choice for pipe welding, steel fabrication, and maintenance in industries that demand the highest performance and reliability. Whether you’re working on industrial projects, on-site repairs, or structural welding, this machine will help you achieve the best possible welds with ease and efficiency.
For more information on welding techniques and applications, check out the Wikipedia article on Welding.
Input Specifications:
Output Specifications:
Other Specifications:
Mechanical Specifications:
SUITABLE FOR:
Heavy-Duty Industrial Applications
Construction Sites
Pipe Welding (Oil & Gas Industries)
Welding Steel, Stainless Steel, & Carbon Steel
On-Site Welding Tasks
Welding with Cellulosic Electrodes (E6010, E7010, E8010, E9045)
WELDABLE MATERIALS:
Steel
Mild Steel
Carbon Steel
Stainless Steel
Specialty Metals
ELECTRODE TYPE & DIAMETER:
JOB THICKNESS:
STANDARD ACCESSORIES:
NOTE: Continuous development entitles us to change specifications without notice. Pictures are for reference only.
Heavy-duty 400 Amp output for industrial welding
Smooth and stable arc for superior weld quality
Designed for continuous duty cycle
Compatible with a wide range of welding electrodes
Robust transformer-based design for long service life
Easy operation with minimal maintenance
Suitable for both site work and workshop applications
The Genesis 400 Star Arc Welding Machine is widely used in:
Structural steel fabrication
Heavy engineering industries
Power plants and infrastructure projects
Shipbuilding and repair yards
Industrial maintenance and repair work
Pressure vessels and metal construction
APS Welding machines are manufactured in compliance with recognized international and national standards to ensure reliability and safety:
These certifications ensure high reliability, operational safety, and consistent performance
for heavy industrial welding applications
Trusted Indian welding machine manufacturer
Proven performance in heavy-duty applications
Strong after-sales support and service network
Competitive pricing with industrial-grade quality
Machines tested for durability and efficiency
The Genesis 400 Star supports Stick Arc Welding (SMAW) and is suitable for a wide range of industrial electrodes.
Yes. The machine is specifically designed for continuous heavy-duty industrial operations.
Absolutely. Its robust construction makes it ideal for on-site and outdoor welding applications.
It is commonly used in fabrication units, infrastructure projects, power plants, shipyards, and heavy engineering industries.
Yes. The optimized transformer design ensures efficient power consumption with stable arc output.
Yes. APS Welding offers technical support, service assistance, and spare availability.
Looking for a reliable 400 Amp arc welding machine for industrial use?
Contact APS Welding today to get the best price, technical guidance, and fast delivery.
